Power
Standby (kVA)
46 kVA
Continuous (kVA)
42 kVA
50 / 60Hz available
50 Hz
Motors
Engine Model
KDI2504TCR
Engine Manufacturer
Kohler
Noise at 7 metres
67 dB
Alternator Manufacturer
Leroy Sommer
Weight
Dry (kg)
1,100 kg
Weight (kg)
1,400 kg
Fluids
Fluid Capacities
Fuel (Litres)
185 Litres
AdBlue (Litre)
N/A
Fluid Consumption
Fuel Consumption at 70% 50Hz
8.3 l/h
AdBlue per hour at 70% (litre)
N/A
Operational Hours
Running on internal day tank at 70%
22 hrs
Dimensions
Dimensions (LxWxH)
2.30 x 1.13 x 1.58 m
Electrical Connection
Outgoing Electrical Connections
1 x 63A 3Φ
1 x 32A 3Φ
1 x 32A 1Φ
Generator Hire or Help & Advice
Capability:
- Compliant Stage V engine technology
- Remote monitoring enabled
- Hot dipped galvanised powder coated canopy
- Road towable
- Central lifting point
- Forklift pockets
- Fully bunded (all liquids)
- Bund alarm to avoid any external leaks
- 3-way fuel valve for external fuel tank connection
Control & Electrical/Mechanical Protection:
- DeepSea 7310 MKII generator controller
- Motorised 4 pole circuit breaker with earth leakage protection
- Hardwire with microswitch protection over busbar door
- Battery isolator
- Emergency Stop
- Engine safety protection shutdown alarm
- DPF filter complete with LED status display
Dimensions - click to enlarge
